Description
Product Overview
The MTTXY Z-Axes Linear Translation Stage is engineered for high‑precision positioning in demanding scientific and industrial environments. Constructed from a lightweight yet rigid aluminum alloy, the platform combines durability with excellent vibration damping, ensuring consistent performance over extended use. The stage features a 60 mm travel stroke and a maximum load capacity of 20 kg, allowing users to handle a wide range of equipment, from delicate optical components to heavier semiconductor wafers. Its scissor‑shaped lifting support provides a stable base while minimizing the footprint, and the precision screw drive delivers sub‑micron incremental movement for fine‑tuning adjustments. The dual‑rail five‑axis over‑positioning mechanism eliminates backlash, guaranteeing repeatable accuracy and smooth motion throughout the entire travel range. With a pitch of 1.5 mm, the stage offers both coarse and fine adjustment capabilities, making it versatile for various applications. The compact table size of 120 × 80 mm (4.7 × 3.1 in) fits easily into confined workspaces, and the overall weight of 4.4 lb (2 kg) facilitates easy installation and repositioning without sacrificing stability.
Usage
Designed for optical equipment, measuring devices, semiconductor manufacturing tools, testing machines, microscopes, and photographic apparatus, this linear stage adapts to multiple operational scenarios. In optical laboratories, the stage serves as a precise alignment platform for lenses, mirrors, and laser assemblies, where minute adjustments are critical for beam path optimization. Semiconductor fabs benefit from the stage’s high load capacity and low‑friction movement when positioning wafers during lithography or inspection processes. In microscopy, the platform provides a stable base for sample stages, enabling researchers to achieve focus and depth control with minimal drift. The quiet, friction‑resistant design also makes the stage suitable for vibration‑sensitive environments, such as interferometry setups or precision metrology stations. Its straightforward manual operation eliminates the need for complex control electronics, allowing technicians to quickly set up and adjust the system without extensive training. The stage’s compatibility with standard mounting brackets and its straightforward integration into existing rigs further streamline deployment across diverse workflows.
Why Choose Us
MTTXY’s commitment to quality is reflected in the meticulous engineering of the Z‑Axes Linear Translation Stage. Each component undergoes rigorous testing to verify dimensional accuracy, load endurance, and long‑term wear resistance, ensuring that the stage maintains its performance specifications over years of operation. The aluminum alloy body is not only lightweight but also corrosion‑resistant, extending the product’s service life even in humid or chemically active environments. Our design incorporates a scissor‑shaped lifting support that distributes load evenly, reducing stress concentrations and enhancing overall stability. The precision screw drive and five‑axis over‑positioning mechanism are manufactured to tight tolerances, delivering repeatable positioning with minimal backlash. Additionally, MTTXY provides comprehensive technical documentation, responsive customer support, and an optional after‑sales service package that includes calibration assistance and spare part availability. By choosing this stage, customers gain a reliable, high‑performance solution backed by a manufacturer that prioritizes durability, precision, and user satisfaction.
Key Features
- Aluminum alloy construction offers a lightweight yet robust platform for long‑term durability.
- 60 mm stroke and 20 kg load capacity enable handling of both delicate and heavier components.
- Scissor‑shaped lifting support provides stable support while minimizing footprint.
- Precision screw drive with 1.5 mm pitch delivers smooth, sub‑micron fine‑tuning adjustments.
- Comprehensive after‑sales support includes calibration assistance and readily available spare parts.
FAQ
What is the maximum load the stage can support?
The stage is rated for a maximum static load of 20 kg, allowing it to safely carry a variety of equipment and samples.
Can the stage be used with motorized drives?
While the stage is designed for manual operation, it can be adapted to motorized drives with appropriate mounting hardware, provided the drive does not exceed the specified load limits.
What is the positioning accuracy of the stage?
Thanks to the precision screw drive and five‑axis over‑positioning mechanism, the stage achieves repeatable positioning accuracy within a few micrometers, suitable for high‑precision applications.
Is the aluminum body resistant to corrosion?
Yes, the anodized aluminum alloy is treated to resist corrosion, making it suitable for use in humid or mildly corrosive environments.
How do I maintain the stage for optimal performance?
Regularly clean the guide rails with a lint‑free cloth, avoid exposure to extreme temperatures, and periodically check the screw drive for wear. Following these simple maintenance steps will ensure consistent performance over the product’s lifespan.
