60mm XYR Axis Trimming Linear Stage Bearing LS60-CM by BATTEMALL

Description

Product Overview

The 60mm XYR Axis Trimming Platform Linear Stage Bearing Tuning Sliding Table (model LS60-CM) is engineered for high‑precision linear motion in demanding industrial and scientific applications. Constructed from a solid aluminum alloy body, the platform combines lightweight durability with excellent rigidity, ensuring consistent performance over prolonged use. The integrated cross roller bearing system provides ultra‑smooth travel with minimal friction, while the micrometer adjustments allow fine‑tuning of the XY travel range (±6.5 mm) and R‑axis rotation (±5°). This combination of precision engineering and robust materials makes the LS60-CM a versatile solution for equipment positioning, inspection rigs, and automation setups.

Key specifications include a compact package size of 1.57 × 1.57 × 1.5 in, a weight of 1.76 lb, and a design that supports easy integration into existing machinery. The platform’s low profile and modular mounting options enable seamless installation on a variety of frames, from benchtop test rigs to larger production lines. Its high‑accuracy machining tolerances guarantee repeatable positioning, which is essential for tasks such as optical alignment, micro‑fabrication, and precision measurement.

Usage

Designed for a broad spectrum of environments, the LS60-CM excels in machine tools, automation equipment, optical devices, and laboratory inspection stations. In manufacturing settings, it provides reliable linear motion for component feeding, tool alignment, and part positioning, reducing cycle times and improving overall efficiency. Automation engineers appreciate the platform’s ability to deliver precise, repeatable movements for robotic pick‑and‑place systems, where even sub‑millimeter deviations can affect product quality.

In optical laboratories, the platform’s fine R‑axis adjustment enables delicate tilting of lenses, mirrors, and sensors, facilitating accurate alignment and calibration procedures. Researchers conducting material testing or micro‑scale experiments benefit from the low‑friction bearing system, which minimizes mechanical interference and allows for smooth, controlled motion during data acquisition. The platform’s compact dimensions also make it suitable for space‑constrained workstations, where maximizing usable area is critical.

Furthermore, the LS60-CM is compatible with a range of control electronics, including stepper motor drivers and PLC interfaces, allowing users to integrate it into custom motion control schemes. Whether used as a standalone positioning table or as part of a larger multi‑axis system, the platform delivers consistent performance across diverse applications.

Why Choose Us

Choosing the LS60-CM means selecting a product backed by rigorous quality assurance processes and a commitment to customer satisfaction. Each unit undergoes comprehensive testing for dimensional accuracy, bearing performance, and load capacity before leaving the factory, ensuring that you receive a component that meets exacting standards. Our aluminum alloy construction is sourced from reputable suppliers, providing a balance of strength and corrosion resistance that extends the platform’s service life even in harsh environments.

We differentiate ourselves through meticulous craftsmanship and attention to detail. The cross roller bearing is precision‑ground to reduce wobble and maintain straight‑line travel, while the micrometer adjustment mechanisms are engineered for smooth operation and long‑term durability. In addition, our technical support team offers guidance on installation, calibration, and integration, helping you achieve optimal results quickly.

Our after‑sales service includes a one‑year warranty covering manufacturing defects, as well as access to replacement parts and technical documentation. We understand that downtime can be costly, so we strive to provide rapid response times and reliable solutions to keep your equipment running smoothly.

Key Features

• High‑precision cross roller bearing delivers ultra‑smooth linear motion with minimal friction.
• Aluminum alloy construction offers lightweight strength and excellent corrosion resistance.
• Adjustable XY travel (±6.5 mm) and R‑axis rotation (±5°) enable fine‑tuning for diverse applications.
• Compact footprint (1.57 × 1.57 × 1.5 in) fits easily into tight workspaces and modular setups.
• Dedicated technical support and one‑year warranty ensure reliable after‑sales service.
